Epson - Epson SureColor T7770DL

44" large-format printer - color - ink-jet - - 2400 x 1200 dpi - up to 1399.3 sq.ft/hour (mono) / up to 1399.3 sq.ft/hour (color) - capacity: 2 rolls - Gigabit LAN, USB 3.0, Wi-Fi(ac) - cutter

Epson
SCT7770DL
N/A
0010343965201
N/A
New

Price: $8,543.48

Total Available: 2

Product Description

Additional Details

What's Included

Specifications

Main Specifications
Product Description Epson SureColor T7770DL - large-format printer - color - ink-jet
Printer Type 44" large-format printer - ink-jet - color
Weight 363.76 lbs
Inkjet Technology Epson PrecisionCore MicroTFP
Ink Palette Supported (Colors) 6-ink - cyan, magenta, yellow, red, photo black, matte black
Max Media Size Roll (44 in)
Min Media Size (Custom) 8 in x 8 in
Max Media Size (Custom) 44 in
Print Speed Up to 1399.3 sq.ft/hour - B0 (39.37 in x 55.67 in) ¦ Up to 0.3 min/page - A1 (23.4 in x 33.1 in) ¦ Up to 300.3 sq.ft/hour
Max Resolution (B&W) 2400 x 1200 dpi
Max Resolution (Color) 2400 x 1200 dpi
Max Resolution Class (B&W) 2400 x 1200 dpi
Max Resolution Class (Color) 2400 x 1200 dpi
Image Enhancement Technology EPSON Variable-sized Droplet Technology
Cutter Yes
Interface Gigabit LAN, USB 3.0, Wi-Fi(ac)
RAM Installed (Max) 4 GB
Language Simulation HP RTL, HP GL/2, EPSON ESC/P Raster, PDF 1.7, Adobe PostScript 3
Media Type Plain paper, poster board, continuous paper
Total Media Capacity 2 rolls
Networking Print server
Printer Features Replaceable Ink Pack System (RIPS), auto take up reel
Power AC 110-240 V
System Requirements Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Microsoft Windows XP (32/64 bits), Microsoft Windows Server 2003 R2 SP2 or later, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Vista / 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016, Apple MacOS X 10.9.5 or later, Microsoft Windows Server 2019, Apple macOS 11 or later
Manufacturer Warranty 1-year warranty
Dimensions (WxDxH) 72.8 in x 19.6 in x 38.4 in
General
Printer Type 44" large-format printer - ink-jet - color
Expansion / Connectivity
Connections 1 x USB 3.0 ¦ 1 x Gigabit LAN
Manufacturer Warranty
Service & Support Limited warranty - 1 year - on-site - response time: next business day ¦ Technical support - phone consulting - 1 year / Monday-Friday
Miscellaneous
Included Accessories 2 roll adapters, USB stick, start here poster
Consumables Included 1 x maintenance box
Compliant Standards FCC Class B certified, RoHS, NRTL, UL/CSA/EN 62368-1
Printer
Inkjet Technology Epson PrecisionCore MicroTFP
Ink Palette Supported (Colors) 6-ink - cyan, magenta, yellow, red, photo black, matte black
Nozzle Configuration 6 x 1600 nozzles
Minimum Ink Droplet Size 3.5 pl
Ink Cartridge Configuration 6 individual ink tanks
Ink Type Epson UltraChrome XD3 Ink
Print Speed Up to 1399.3 sq.ft/hour - B0 (39.37 in x 55.67 in) ¦ Up to 0.3 min/page - A1 (23.4 in x 33.1 in) ¦ Up to 300.3 sq.ft/hour
Built-in Devices 4.3 inch LCD touch screen
Connectivity Technology Wireless
Interface Gigabit LAN, USB 3.0, Wi-Fi(ac)
Max Resolution (B&W) 2400 x 1200 dpi
Max Resolution (Color) 2400 x 1200 dpi
Max Resolution Class (B&W) 2400 x 1200 dpi
Max Resolution Class (Color) 2400 x 1200 dpi
Image Enhancement Technology EPSON Variable-sized Droplet Technology
Language Simulation HP RTL, HP GL/2, EPSON ESC/P Raster, PDF 1.7, Adobe PostScript 3
Cutter Yes
Printer Features Replaceable Ink Pack System (RIPS), auto take up reel
RAM
RAM Installed (Max) 4 GB
Media Handling
Media Type Plain paper, poster board, continuous paper
Max Media Size Roll (44 in)
Min Media Size (Custom) 8 in x 8 in
Max Media Size (Custom) 44 in
Media Sizes A1 (23.4 in x 33.1 in), B0 (39.37 in x 55.67 in), Roll (25.4 - 111.8 cm)
Borderless Photo Sizes Roll (10 in), Roll (16 in), Roll (44 in), Roll (17 in), Roll (36 in), Roll (13 in), Roll (24 in), Roll (20 in)
Media Thickness Range Up to 0.06 in
Total Media Capacity 2 rolls
Media Feeders 2 x manual - Roll (44 in)
Networking
Networking Print server
Power
Power Device Power supply
Voltage Required AC 110-240 V
Frequency Required 50/60 Hz
Power Consumption Operational 75 Watt
Power Consumption Stand by 32 Watt
Power Consumption Sleep 2 Watt
Software / System Requirements
Software Included Drivers & Utilities
OS Required Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2008, Microsoft Windows XP (32/64 bits), Microsoft Windows Server 2003 R2 SP2 or later, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Vista / 7 / 8 / 8.1 / 10, Microsoft Windows Server 2016, Apple MacOS X 10.9.5 or later, Microsoft Windows Server 2019, Apple macOS 11 or later
Environmental Parameters
Min Operating Temperature 50 °F
Max Operating Temperature 95 °F
Humidity Range Operating 20 - 80% (non-condensing)
Sound Emission (Operating) 49.6 dBA
Dimensions & Weight
Width 72.8 in
Depth 19.6 in
Height 38.4 in
Weight 363.76 lbs
Environmental Standards
ENERGY STAR Yes
